Packer Bottles · Spec sheet IT-CA-104
Packer Bottle 200 mL 23.2g R-38
Packer Bottle 200 mL 23.2g R-38 in Virgin PET with R-38 neck finish · 248 pieces per box. Technical data sheet controlled under ISO 22000.
Capacity200 mL
Neck finishR-38
MaterialVirgin PET
Piece weight23.2 g
Fill up to55°C
To the brim235.00 mL ±10
Pieces per box248
It’s already in your quote.
View my quote and send it
01
Measurements and tolerances
Spec sheet IT-CA-104 · Rev. 0| Dimension | Measurement and tolerance |
|---|---|
| HHeight | 109.5 mm±0.35 |
| MWidth | 58.3 mm±0.50 |
| TThread Ø | 36.76 mm±0.50 |
| EOuter Ø (no thread) | 34.53 mm±0.50 |
| IInner mouth Ø | 31.6 mm±0.50 |
Wall thickness
| 2Body thickness | 0.45 mm±0.30 |
| BBase thickness | 0.4 mm±0.30 |
These are process-control measurements, not selection ones: they define how the piece is blown. They come in full on the downloadable data sheet.
02
Packaging and shipping
02
Colors
The most requested on this piece- Clear (transparent)
- Amber
- Blue
- Green
- White
The circles indicate the color, not a photo of the piece in that color. It is pigmented to the Pantone you request: these are the most commonly used and the list doesn’t end here. To approve a shade you must request a physical sample.
It is released against this data sheet, with acceptance criteria by defect class. How it is inspected · Download the full technical data sheet
